MECHANICAL AND ELECTRICAL INSTALLATION OF THE STACKING SYSTEM AT THE END OF THE STAMPING LINEMECHANICAL AND ELECTRICAL INSTALLATION OF THE STACKING SYSTEM AT THE END OF THE STAMPING LINE
Name of contract: Mechanical and electrical installation in MA Treuen
Term of delivery: 2017
SPECIFICATION
The project was implemented at the customer’s request for a mechanical and electrical installation.
DESCRIPTION OF THE AUTOMATED OPERATION
1. At the end of the stamping line is a conveyor used to transport the final products, in this case car roofs, to their storage location.
2. The robot grabs the product and places it on a pallet in a rack.
3. The robot, which travels on the seventh axis, puts foam parts from the trolleys between the individual parts of the products.
4. A total of 4 robots work on the device, which stacks the products into 4 racks.
BASIC CHARACTERISTICS
The final products are handled by ABB robots with grippers of our own design. Transport between the stamping line and the storage racks is done with a belt conveyor.
