Automated machine for 3D surface quality control

Automated machine for 3D surface quality control
Automated machine for 3D surface quality control

AUTOMATED QUALITY CONTROL OF SURFACE ROUGHNESS AND ACCURACY OF THE HOLE IN PARTS

Name of contract:      Automated insertion of parts into customer trays
Term of delivery:        2018-2019



SPECIFICATION

Line cycle:     2 sec / pc

Availability

  • The machines are operated in three shifts, 23.5 hours a day, 360 days a year.
  • The required mechanical availability is 97.9%.
  • The maximum downtime must not exceed 120 minutes at a time.

Process stability

  • The required process stability is: 99.9937%
  • The required Cpk value is at least: 1.33



DESCRIPTION OF THE AUTOMATED PROCESS:

The operator loads the galvanic blisters into the input tray, then the robot removes these parts and places them on the carousel, where the surface roughness is checked, as well as the hole in the parts. The second robot then puts them into the customer’s blisters, which the operator inserts into the input tray for the customer’s blisters. Once the blisters are ready, they are stacked in a column and moved to an output conveyor, from which the columns are removed by the operator.
The machine is designed for one worker, who performs tasks according to the operating manual. The process is controlled by the SIMATIC S7-1500 control system.

According to customer requirements, the processing machine is equipped with product inspection:

  • Checking the surface of the sealing surface – the machine must sort out pieces with defects exceeding the customer specification of Ra 1.6 and Rzmax 10.
  • Inspection of the entire inside of the product using a camera to detect defects and damage.

Example of defects on the inside of the products:

Example of defects on the inside of the products



Základní charakteristika našeho řešení:

  • 2 OMRON SCARA ROBOTS
  • PLC SIEMENS S7-1500
  • OMRON CAMERA INSPECTION
  • KEYENCE 3D SCANNER

Key benefits of our solution

  • Dependability under demanding operating conditions
  • Camera inspection of product defects

image​​​​​​View of the machine after implementation

imageInserted into collets on the carousel

imageView of the carousel

imageCamera inspection

imageOperator control panel

imageOK pieces retained
